IP66 dustproof hinged junction box aluminum junction box electrical terminal box 340*235*155mm

IP66 dustproof hinged junction box aluminum junction box electrical terminal box 340*235*155mm

  • IP66 dustproof hinged junction box aluminum junction box electrical terminal box 340*235*155mm
IP66 dustproof hinged junction box aluminum junction box electrical terminal box 340*235*155mm
Product Details:
Place of Origin: China
Brand Name: CNXY
Certification: CE, RoHS
Model Number: M4-342315
Payment & Shipping Terms:
Minimum Order Quantity: 10
Packaging Details: common carton
Delivery Time: samples 2-3 working days, large quantity 7-20 working days
Payment Terms: T/T, Western Union, paypal
Supply Ability: 1000pcs per week
Contact Now
Detailed Product Description
Material: Aluminum IP Grate: IP65
Color: Grey Size: 340*235*155mm
OEM: Yes Weight: 0.58kg
High Light:

aluminum enclosure box

,

aluminium junction box

IP66 dustproof junction box aluminum junction box electrical terminal box 100*100*80mm

This series aluminum waterproof box is applied in connection boxes, module cases, control boxes and other types of electronics.
1.Made of Aluminum.
2. Protection rank up to IP 66-67
3.Better anti-corrosion performance; protect instruments even under the adverse environment.
4.Color and material can be changed as your interesting.
5.Certain modification can be done according to your requirements; such as drilling, painting, punching, silk-screen printing? power coating and etc.
6. Your design is welcome, the mould fee can be offset when future order reaches a certain amount.



Model NumberM4-101008
Size100*100*80 mm
MaterialAluminium
ColorBlack/ White/ Silver/ Customized
Protect GradeIP66
FunctionWaterproof, Dustproof , Musical Effect
CertificationCE, RoHS


Sizes available.

ModelSize
M4-06050364*58*35
M4-120805120*80*55
M4-120805-2120*80*55
M4-130805135*85*56
M4-120805-3125*80*58
M4-181207188*120*78
M4-181207-2188*120*78
M4-100605100*68*50
M4-221405222*145*55
M4-221405-2222*145*55
M4-221407222*145*75
M4-221408222*145*80
M4-110603111*64*37
M4-181405180*140*55
M4-09030390*36*31
M4-221507228*150*75
M4-201307200*130*78
M4-181308185*135*85
M4-221509220*155*95
M4-251808250*185*88
M4-251909250*190*90
M4-08070680*75*60
M4-170805175*80*56
M4-170808175*80*80
M4-250806250*80*60
M4-250808250*80*80
M4-110605115*65*55
M4-161006160*100*60
M4-151008150*100*80
M4-110905115*90*58
M4-110906115*90*60
M4-251208250*120*82
M4-321209320*120*90
M4-361609360*160*95
M4-101006100*100*60
M4-141407140*140*75
M4-141004145*100*45
M4-121208120*120*82
M4-161607160*160*70
M4-161609160*160*90
M4-161608160*160*86
M4-241607240*160*75
M4-241610240*160*100
M4-261807265*185*75
M4-261809260*185*96
M4-261812260*185*128
M4-302110300*210*100
M4-302110300*210*130
M4-342309340*235*95
M4-342312340*235*120
M4-342313340*235*135
M4-342316340*235*160






































































Details:

 IP66 dustproof hinged junction box aluminum junction box electrical terminal box 340*235*155mm 0IP66 dustproof hinged junction box aluminum junction box electrical terminal box 340*235*155mm 1
IP66 dustproof hinged junction box aluminum junction box electrical terminal box 340*235*155mm 2

Features:

1.The metal emergency stop button enclosure is made of high quality aluminum alloy, and the surface is high speed polished and then sprayed.
2.It is equipped with sealed rubber strip, making the enclosure dustproof, waterproof, anti-aging and partly anti-corrosion.
3. With good outlook, the normal color is gray, RAL-7032. The color can be customized according to the customer's requirements, such as white, yellow and black. Customized logo could be added on the enclosure.
4.According to customer requirements, we could make holes such as ordinary round holes, holes with silk tapping, square holes. Various button switches, indicator lights and waterproof connectors can be installed.Button can be equipped with a protective cover to prevent damage to the button caused by rain, dust, etc. The thread could go through the waterproof cable gland thus keeping the enclosure well sealed.
5. There’s mounting studs at the bottom, easy to install various accessories, such as guide rail, terminal, etc.
6 Mounting plate available when customer requires.
7 Installation:

  • The enclosure can be directly fixed on the wall or other flat boards with screws or or nails via the screw hols in the base.
  • The enclosure can be fixed by mounting brackets.



Service:

1.Any shape hole could be drilled by laser cutter . (Grand connected for wire through)
2.Silk-screen and Laster pring could be done. (Show your company logo and name)
3.Mounting place could be done. (Install other electronic enclosure)
4.The material and color of the products could be modified as required.
5.New mould for your customized design could be accepted.

IP66 dustproof hinged junction box aluminum junction box electrical terminal box 340*235*155mm 3
